Frame:
Reynolds 520 steel, 44mm head tube, 31.6 I.D. seat tube, internal dropper post routing, ISCG05, sliding 12x148mm dropouts, Formula axle
Fork/Headset:
Rock Shox Recon Silver RL 29/27.5+, Solo Air spring, external rebound, lockout adjust, 32mm stanchions, 15x110mm axle, tapered aluminum steerer, 120mm travel
Crankset/Bottom Bracket:
SRAM NX
Pedals:
Raceface Blue
Drivetrain/Cog/Chainring/Chain:
SRAM NX, 32T, 170mm (15”), 175mm (17-21”)/SRAM 1130, 11-speed, 11-42T
Derailleurs/Shifters:
SRAM NX, 11-speed/SRAM NX, 1×11-speed
Saddle/Seatpost:
WTB Volt Sport
Brakes:
Shimano M396 hydraulic disc, 180mm front & 160mm rear RT26 6-bolt rotors
Front Wheel/Hub/Tire:
WTB Scraper i40 TCS tubeless 27.5″ rims, Formula sealed bearing 15x110mm front & 12x148mm rear 6-bolt disc hubs, stainless spokes
Rear Wheel/Hub/Tire:
WTB Scraper i40 TCS tubeless 27.5″ rims, Formula sealed bearing 15x110mm front & 12x148mm rear 6-bolt disc hubs, stainless spokes
